AK Telecom
N300 Wi-Fi XPON ONT S-XPON-1000-WDONT-R
Model XPON-1000
N300 Wi-Fi XPON ONT S-XPON-1000-WDONT-R Description: NEO 300 Wi-Fi Gpon/Epon ONT ROUTER Model No: S-XPON-1000-WDONT-R Key Features: Ideal solution for FTTH solution Downstream 2.5Gbps and Upstream rate is up to 1.25Gbps and transmission distance is up to 20Km. 2.4G Wi-Fi, 300Mbps wireless speed 2 *…
Description
EPON/GPON Interface:
- SC/UPC single mode single fiber
- GPON: FSAN G.984.2 standard, Class B+
- EPON: 1000BASE-PX20+ symmetric
- GPON: 2.5Gbps/1.25Gbps downstream/upstream
- EPON: 1.25Gbps downstream/upstream
- Wavelength: Transmit: 1310nm Receiver 1490nm
- Receiving sensitivity: GPON -28dBm, EPON -27dBm
- Saturated power: GPON -8dBm, EPON -3dBm
- Transmitting power: GPON : 0.5 — 5dBm, EPON: 0 — 4dBm
- 1*10/100/1000M auto-negotiation
- Full/half duplex mode, RJ45 connector
- Auto MDI/MDI-X, 100m distance
- Power Interface: 12V DC Power supply
- Management Mode: OMCI, OAM, TR069, WEB, Telnet
- Management Function: Status monitor, Configuration management, Alarm management, Log management
- Power: <4W, 12V/0.5A power supply adapter
- Product Dimension: 228mm(L) x108mm(W) x 28mm (H)
- Weight: Net Weight: about 136g
- Operating temperature: 0 to 40°C | Operating humidity: 10% to 90%(Non-condensing)
- Operating Mode: Router or bridge
- Technical standard: I EEE802.11b/g/n
- Frequency: 2.412 — 2.472 GHz
- Antenna Gain: 5dBi
- Support rate: 802.11b: 1, 2, 5.5, 11Mbps | 802.11g: 6, 9, 12, 24, 36, 48, 54Mbps | 802.11n max rate 300Mbps
- Channel: 2.4GHz Channel 1,2,3,4,5,6,7,8,9,10,11,12,13
- Encryption mode: AES, TKIP, WPA, WPA2, WPA-PSK/WPA2-PSK
- Modulation Mode: 11 b DSSS DBPSK(1 Mbps), DQPSK(2Mbps), | CCK(5.5/11Mbps), 11 g: OFDM:BPSK(6/9Mbps), QPSK(12/18Mbps),16QAM(24/36Mbps) | Q64QAM(48/54Mbps) | 11 n MIMO-OFDM:BPSK,QPSK,I6QAM,64QAM
- Receive sensitivity: 11Mbps -90dBm | 54 Mbps -76dBm, HT20 MCS7-73dBm | HT40 MCS7 -70dBm
- Transmit Power : 802, 11n 17dBm
Enquire about the N300 Wi-Fi XPON ONT S-XPON-1000-WDONT-R
Tell us the quantity and destination. We will confirm stock or give you a real delivery date.
Product: N300 Wi-Fi XPON ONT S-XPON-1000-WDONT-R · Model XPON-1000
